Product Details
Certification: CE
Payment & Shipping Terms:
Minimum Order Quantity: 1Set
Price: Negotiable
Packaging Details: 1*40GP container
Delivery Time: 30days
Payment Terms: L/C, D/A, T/T, D/P, Western Union
Detailed Product Description
Application:: | All Metal Material | Cutting Thickness: | 0.1-22mm |
---|---|---|---|
Laser Type:: | Fiber | Laser Power: | 500W/700W/1000W/1500W/2000W/3000W/4000W |
Min.line Width: | 0.1mm | Control Software:: | Cypcut |
Graphic Format Supported:: | AI, BMP, DST, DWG, DXF, DXP, LAS, PLT | Brand:: | TAIYI LASER |
Repeating Accuracy:: | +/-0.03mm | Operating Temperature:: | 0°C-45°C |
Cooling Mode: | Water Cooling | Laser Source: | IPG/Nlight/Raycus/Max |
Voltage:: | AC380V±10% 50HZ(60HZ) | Cutting Area: | 3000x1500mm Or Customized |
Feature & Property
1.The machine enjoys a good performance with high cutting speed, high efficiency, safety and stability. And diode pump solid state laser has the advantage of longer working life, free maintenance and the highest IPCE. It also ensures a small divergence angle and light beam of good quality.
2.The light spot enjoys good quality. And the machine distorts just slightly. Besides, the material can have a smooth and nice appearance.
3.After tempering treatment, the frame with high rigidity is of high vibration-absorbed performance. The frame with gantry structure is one-step processed in large CNC gantry machining center. With optimized structure, the machine enjoys stability and high accuracy which can be controlled within 0.01mm/m.
4.Imported servo motor, planetary reducer, and sophisticated direction drive mechanism ensure steadiness and accuracy.
5.Intuitive HMI with many practical functions is easy to operate.
6.Imported bevel gear, helical rack, linear guide rail ensure highly precise running direction.
7.The auto-height & anti-collision system automatically adjusts the hermetic cutting head at the proper height to cut at a fixed distance.
8.The power supply of the machine is designed with automatic safety protection, and features fault alarm.
9.With fashionable, delicate and artistic design, the compact machine covers smaller floor area without scattered parts. And it’s easy to operate the machine.
Specification
Laser source medium | Fiber |
Cutting range (L * W) | 3000 mm × 15000 mm |
Z axle stroke | 250 mm |
Max. positioning speed | 120 m/min |
X,Y axle Max. accelerate speed | 1.0G |
Cooling form | Water cooling |
Laser wavelength | 1070nm |
Output power of laser source
| 500W/1000W / 1500W / 2000W 2500W / 3000W / 4000W (Optional) |
Min. cutting gap | ≤ 0.1 mm |
Positioning accuracy of X, Y and Z axles | ± 0.03 mm |
Repeated positioning accuracy of X, Y and Z axles | ± 0.01 mm |
Thickness of cutting material (according to material) | 0.2 - 25 mm |
Driver model | Imported servo motor |
Power requirement | 380V, 50/60 Hz |
Working temperature | 0-45℃ |
Continuous working time | 24 Hours |
Machine weight | About 12000 Kgs |
Total protection level of power supply | IP54 |
Aplication
It’s applicable to cut stainless steel, carbon steel, brass, aluminum and other materials.It has been widely used in many fields including sheet metal, aeronautics and astronautics, electronics, electrical equipment, subway parts, automobile, crops machine, textile machine, engineering machine, sophisticated fittings, ship manufacturing, metallurgical equipment, elevator, household appliance, crafts & gifts, tools, ornament, billboard, metalworking and other industries.
Detailed Images
Name: Machine body and accessoriea.600℃ heat treatment, 24 hours cooling in the oven, accurate CO2 protection welding, to make sure 20 years usage without deformation. b.Synchronous X/Y/Z axes: The Z-axis can run 150mm, suitable for cutting many varieties of metal sheets. c.High quality guarantees its durability and easier maintenance. | |
Name:AC servo motor & driverThe imported servo motor (Y-axis driven by two servo motors) along with the sophisticated planetary reducer ensures steady, precise and reliable drive. | |
Name:Precision Linear GuidesAdvanced cutting system, laser power and servo movement suit each other perfectly, imported high precision gear and rack drive system, exchangeable double work table, to ensure higher processing speed and accuracy.. | |
Name:Cutting headThe contactless cutting head has the function of auto height tracking and anti-collision, which greatly improves cutting speed, smoothness and cutting accuracy under the same output power. In a word, the cutting efficiency can be increased. | |
Name:Laser sourcefast speed,high precision cutting line, and smooth cutting edge |
Cutting Samples
Training
After-sales service, from training to machine installation (3 ways):
1.Training video and user's manual in English to be offered for installation, operation, maintenance and trouble-shooting, and technical guide to be offered by e-mail, fax, telephone/whatsapp /skype//and so on, when you meet some problems of installation, using or adjusting.
2.Your company can arrange technologist come our factory to learn basic knowledge of equipment and operating essentials , sufficient training time about 3-5days , the training content is as follows:
a) Common drawing software training ;
b) Machine on and off training procedures ;
c) The significance of control panel and software parameters, parameters range’s setting
d) Basic cleaning and maintenance of the machine ;
e) Common Hardware Troubleshooting ;
f) Caution of operation.
3.Door-to-door instruction training service. visa, traveling expenses and accommodation will be at customer's cost. It's better to arrange a translator for both of our engineers during the training period. Training Time: 3-5days.
Our Services
Pre-Sales Service
1. We have many exhibitions very year, hundreds of clients was coming to our booth for further communication.
2.24-hours online Inquiry and consulting support.
3. Sample testing support.
4. We welcome you to visit our factory.
After-Sales Service
1. Training how to install the machine, training how to use the machine online.
2. Engineers available to clients' factory for training.
