Detailed Product Description


Application::All Metal MaterialCutting Thickness:SS Upto 12mm, MS Upto 22cm
Laser Type::Imported Original Fiber LaserName:Fiber Laser Cutting Machine
Min.line Width:0.1mmGraphic Format Supported::AI, BMP, DST, DWG, DXF, DXP, LAS, PLT
Max Acceleration:1GRepeating Accuracy::+/-0.03mm
Operating Temperature::0°C-45°CCooling Mode:Water Cooling
Weight(kg):4600Voltage::AC380V±10% 50HZ(60HZ)

Advantage of fiber laser machine


1. Excellent path quality: Smaller laser dot and high work efficiency, high quality.
2. High cutting speed: cutting speed is 2-3 times than same power CO2 laser cutting machine.
3. Stable running: adopt top world import fiber lasers, stable pe
rformance, key parts can reach 100,000 hours;
4. High efficiency for photoelectric conversion: Compare with CO2 laser cutting machine, fiber laser cutting machine have three times photoelectric conversion efficiency.
5. Low cost: Save energy and protect environment. Photoelectric conversion rate is up to 25-30%. Low electric power consumption, it is only about 20%-30% of traditional CO2 laser cutting machine.
6. Low maintenance: fiber line transmission no need reflect lens, save maintenance cost;
7 Easy operations: fiber line transmission, no adjustment of optical path.

Main Features of Fiber laser cutting machine


1) Adopting World Famous Germany Dlaser Fiber laser source and USA Laser Mech cutting head &
Dynamic Focus System,it can cut and punch different kind of metal material with high precision
and high speed.
2) Since laser is transmitted by fiber, it is no need to maintenance or adjusts the laser optical path.
It greatly reduces the machines fault rate and prolongs the working life.
3) Large format cutting area meets the demands of various kinds of metal processing.

Specification


Laser source mediumFiber
Cutting range (L * W)3000 mm × 15000 mm
Z axle stroke250 mm
Max. positioning speed120 m/min
X,Y axle Max. accelerate speed1.0G
Cooling formWater cooling
Laser wavelength1070nm


Output power of laser source



500W/1000W / 1500W / 2000W

2500W / 3000W / 4000W

(Optional)

Min. cutting gap≤ 0.1 mm
Positioning accuracy of X, Y and Z axles± 0.03 mm
Repeated positioning accuracy of X, Y and Z axles± 0.01 mm
Thickness of cutting material (according to material)0.2 - 25 mm
Driver modelImported servo motor
Power requirement380V, 50/60 Hz
Working temperature0-45℃
Continuous working time24 Hours
Machine weightAbout 8600 Kgs
Total protection level of power supplyIP54

Cutting Thickness Reference Table


Laser PowerMax cutting thickness
Carbon steel(mm)Stainless steel(mm)Aluminum (mm)Brass

(mm)

700W8311
1000W12422.5
1500W14543
2000W16654
3000W221068
Above parameter for reference only

Application Materials


Fiber Laser Cutting Equipment is suitable for metal cutting like Stainless Steel Sheet, Mild Steel Plate, Carbon Steel Sheet, Alloy Steel Plate, Spring steel Sheet, Iron Plate, Galvanized Iron, Galvanized Sheet, Aluminum Plate, Copper Sheet, Brass Sheet, Bronze Plate, Gold Plate, Silver Plate, Titanium Plate, Metal Sheet, Metal Plate, Tubes and Pipes, etc.



Application Industries


Fiber Laser Cutting Machines are widely used in manufacture Billboard, Advertising, Signs, Signage, Metal Letters, LED Letters, Kitchen Ware, Advertising Letters, Sheet Metal Processing, Metals Components and Parts, Ironware, Chassis, Racks & Cabinets Processing, Metal crafts, metal art ware, elevator panel cutting, hardware, auto parts, Glasses Frame, Electronic Parts, Nameplates, etc.

Detailed Images




Name:Machine body and accessoriesa.600℃ heat treatment, 24 hours cooling in the oven, accurate CO2 protection welding, to make sure 20 years usage without deformation.
b.Synchronous X/Y/Z axes: The Z-axis can run 150mm, suitable for cutting many varieties of metal sheets.
c.High quality guarantees its durability and easier maintenance.
Name:AC servo motor & driverThe imported servo motor (Y-axis driven by two servo motors) along with the sophisticated planetary reducer ensures steady, precise and reliable drive.
Name:Precision Linear GuidesAdvanced cutting system, laser power and servo movement suit each other perfectly, imported high precision gear and rack drive system, exchangeable double work table, to ensure higher processing speed and accuracy..
Name:Cutting head

The contactless cutting head has the function of auto height tracking and anti-collision, which greatly improves cutting speed, smoothness and cutting accuracy under the same output power. In a word, the cutting efficiency can be increased.

Name:Laser sourcefast speed,high precision cutting line, and smooth cutting edge
