full enclosed industrial laser cutting machine 10m / min cutting speed

Product Details

Certification: ISO9001:2008

Payment & Shipping Terms:

Minimum Order Quantity: 1

Price: negotiation

Packaging Details: Wooden case

Delivery Time: 7-15 days

Supply Ability: 1 units/ month

Detailed Product Description

Product Name:	Metal Sheet Fiber Laser Cutting Machine	Laser Power:	1000w 1500w
Laser Wavelength:	1080nm	Working Area:	3000*1500mm
Cutting Thickness:	0-16MM (depends On Laser Power)	Power Supply:	380v
Warranty:	1 Year

Product Desciption

1. Integrated machine design:left and right collecting drawer on the left and right side of the machine,highly saving space.
2. Stability and reliability of light path system and control system.
3. Fiber laser has high and stable function and lifespan which is over 100000 hours.
4. Higher cutting quality and efficiency with cutting speed being up to 25m/min with perfect cutting edge.
5. High performance reducer, gear and rack; Japanese guide and ball screw.

Metal Sheet Fiber Laser Cutting Machine Advantages

1. low usage cost ,only 0.5-1.5km/h power consumption ,can use air to cut thin metal board.
2. High cutting speed , high effeciency,when cutting thin metal board. The speed can arrive 10m/min.
3. High quality of facula,samll deformation ,smooth and beautiful cutting surface.
4. Using import servomotor and Taiwan ball screw and guide rail ,high cutting precision.
5. Using special software to design all kinds of words or figures,then cutting immediately,flexible working and simple operating.
6. High stability,inport the best laser optical maser,steady performance ,that is the most important parts of Fiber cutter.The lifetime of Laser optical maser is 100,000 hours and free maintenance.
7. Low maintenance cost,no need working with air for the laser optical maser,fiber transmission ,no need reflector mirror , can save plenty of maintenance cost.
8. Simple and convenient operating,fiber transmission,no need adjust the light path.

Metal Sheet Fiber Laser Cutting Machine Advantages

Technical Specifications

^{Laser wavelength}	^1080nm
^{Cutting thickness}	^0.2-16mm
^{Laser output power}	^1000W
^{Maximum processing range}	^{3000 *1500mm}
^{Machine drive mode}	^{imported rack gear and pinon drive}
^{Y X. axis positioning accuracy}	^±0.01mm
^{X.Y axis repeat positioning accuracy}	^±0.01mm
^{Power supply mode}	^{380V / 50Hz}
^{Maximum cutting speed}	^45m/min
^{Minimum cutting line width}	^0.02mm
^{Cooling mode}	^{3P Water cooling}

Accessories

Worktable part: the machine adopts double platforms exchange automatically, saving time of loading and unloading materials. High cutting efficiency. Saving time and cost.
The table can carry up to 500KG. The worktable is surrounded by wanxiang ball bearings.
the side of the workbench is installed with the clamping device, which can firmly set the plate on the worktable, so that the plate will not move when the laser is cut.
Transmission
Y axis adopt double drives.
Taiwan Hiwin guide rails and Germany rack and gear
high speed with stability when working
Motors and drives
The X, Y and Z axis are imported servo motors in Japan Yaskawa with high accuracy, high speed, high torque, large inertia and stable performance.
The high speed and speed of the machine are guaranteed
Drives 3kw. high cutting power and precision.
Laser Generator and Laser cutting head
All of our fiber laser cutter are installed with brand name laser generator------Maxphotonics.
Warranty 2 years. low-processing cost and environment-friendly.
Swiss Raytools laser cutting head or Chinese brand name WSX.
Both are high quality and good parameter stability.

Application Industry

Applied to the sheet metal processing, aviation, aerospace, electronics, electrical appliances, subway accessories, automotive, food machinery, textile machinery,engineering machinery, precision parts, ships, metallurgical equipment, elevators, household appliances, gifts, tooling, decoration, advertising , metal external processing,processing, and other kitchenware manufacturing and processing industries.
